| Model No. |
PT-VMZ60 |
PT-VMZ50 |
| Power supply |
AC 100 V–240 V, 50/60 Hz |
AC 100 V–240 V, 50/60 Hz |
| Power Consumption |
420W |
370W |
| LCD Panel |
16.3 mm (0.64 in) diagonal |
16.3 mm (0.64 in) diagonal |
| LCD Panel Aspect Ratio |
16:10 |
16:10 |
| Lamp |
1.6 x Manual zoom (Throw ratio: 1.09–1.77:1)
Manual focus lens, F = 1.60–2.12, f = 15.30–24.64 mm |
1.6 x Manual zoom (Throw ratio: 1.09–1.77:1)
Manual focus lens, F = 1.60–2.12, f = 15.30–24.64 mm |
| Brightness |
- |
- |
| Lens (Throw ratio) |
1.09–1.77:1 |
1.09–1.77:1 |
| Contrast (Full on/full off) |
3,000,000:1 (all white/all black)
(PICTURE MODE: DYNAMIC, DYNAMIC CONTRAST: [1]) |
3,000,000:1 (all white/all black)
(PICTURE MODE: DYNAMIC, DYNAMIC CONTRAST: [1]) |
| Resolution Native/maximum*1 |
1920 x 1200 pixels
(Input signals that exceed this resolution will be converted to 1920 x 1200 pixels.) |
1920 x 1200 pixels
(Input signals that exceed this resolution will be converted to 1920 x 1200 pixels.) |
| Screen Size |
0.76–7.62 m (30–300 in), 16:10 aspect ratio |
0.76–7.62 m (30–300 in), 16:10 aspect ratio |
| Optical Axis Shift |
- |
- |
| Keystone Correction Range |
Vertical: ±25 °, Horizontal: ±35 ° |
Vertical: ±25 °, Horizontal: ±35 ° |
| Dimensions(W x H x D) |
399 mm x 133 mm x 348 mm (15 23/32˝ x 5 1/4˝ x 13 11/16˝ ) (With feet at shortest position) |
399 mm x 133 mm x 348 mm (15 23/32˝ x 5 1/4˝ x 13 11/16˝ ) (With feet at shortest position) |
| Weight |
Approx. 7.2 kg (15.87 lbs) |
Approx. 7.2 kg (15.87 lbs) |
|
| |
